Allen-Bradley 1771-IK Encoder/Counter Module, Precision Motion Control Solutions

Manufacturer:Rockwell Automation

Model:1771-IK

Sub-Model:- Encoder/Counter Module

Module Category:Industrial Control

Operating Voltage:12 to 48 VDC

Communication Protocol:DeviceNet, ControlNet

Input Type:Encoder or Counter

Number of Channels:1

Max. Resolution:Up to 2^31 counts

Accuracy:±0.1% of reading ± 1 count

Environmental Conditions:Operating Temperature: 0 to 50°C, Storage Temperature: -20 to 70°C

Dimensions:2.6 x 4.8 x 1.0 inches (66 x 122 x 25 mm)

Weight:0.2 lbs (90 g)

    Engineered for durability and reliability, the AB 1771-IK Encoder/Counter Module boasts a compact design that seamlessly integrates into various industrial environments. Its high-resolution encoder provides precise feedback for motion control applications, ensuring smooth operation and minimizing errors in production processes.

    The module supports a wide input range, allowing it to accurately measure low to high-speed motions, making it suitable for a broad spectrum of applications from simple conveyor systems to complex robotic arms. Its MODBUS RTU interface facilitates easy communication with PLCs and other automation equipment, streamlining integration and setup.

    Designed for harsh industrial conditions, the 1771-IK Encoder/Counter Module features an IP65 enclosure rating, safeguarding against dust and water ingress. This robust construction ensures longevity and minimal maintenance requirements, even in challenging environments.

    With its ability to count up to 65,535 pulses and achieve accuracy within +/- 0.1% of the reading, this module offers unparalleled precision in position and speed measurement. This precision is critical for applications requiring high accuracy, such as CNC machines, packaging lines, and automated assembly stations.

    The AB 1771-IK Encoder/Counter Module simplifies the setup process with its DIN rail mounting feature, enabling quick installation and easy access for maintenance or upgrades. Its compatibility with a wide range of industrial protocols makes it a versatile choice for modern automation systems, enhancing efficiency and productivity across diverse industries.
