Product Type:Encoder Interface Module
Brand:Bachmann
Model:ISI222
Counter Resolution:32-bit
Output Voltage Range:+5 V to +15 V selectable with jumper, 24 V looped through
Output Voltage:±10 V
Output Current:Max. ±2 mA
Positioning Module Type:2x In INC/SSI, 1 MHz, 32-bit, RS422 level, INC A, A/B/N, position, gate time, period, velocity, encoder supply 5V / 15V / 24V
Positioning Module Outputs:2x Out ±10V, 14-bit, 0.025 %, 40μs, synchronized, PreSYNC
Digital Inputs (DI):4x 24V, trigger, homing
Number of Masters:4 per M1 controller
CAN Buses:2 per module
Max. Number of Nodes:64 per CAN bus
Protocol:CANopen to CiA DS 301
Current Consumption:320 mA / 5 VDC
Transfer Rate:10 k to 1 Mbaud
Operating Temperature:-30 to +60 °C
The Bachmann ISI222 Encoder Interface Module is engineered to enhance the precision and reliability of industrial control systems by providing seamless integration between encoders and automation controllers.
Featuring high-resolution counter capabilities, this module ensures accurate position measurement and feedback, essential for applications requiring high-precision control.
With support for multiple voltage levels and a flexible output configuration, the ISI222 is adaptable to a wide range of encoder types and automation scenarios, ensuring compatibility and performance across diverse industries.
Built with robust materials and designed for durability, the module withstands harsh industrial conditions, ensuring long-lasting operation and minimal maintenance needs.
Simplified installation and user-friendly configuration options make the Bachmann ISI222 Encoder Interface Module accessible to both experienced engineers and those new to industrial automation, streamlining integration into existing systems.
