Brand:Eaton
Model:MTL 8715-CA-BI
Type:Isolator Module
Input Signal Range:0-20 mA / 4-20 mA
Output Signal Range:0-20 mA / 4-20 mA
Supply Voltage:24 VDC
Power Consumption:Typical 2 W
Isolation Voltage:1 kVrms
Response Time:< 1 ms
Environmental Rating:IP20
Operating Temperature Range:-40°C to +85°C
Certifications:ATEX, IECEx, FM, CSA, UL
The Eaton MTL 8715-CA-BI is a highly reliable intrinsically safe isolator designed for use in hazardous environments where explosive gases or dust may be present. This isolator is certified to meet ATEX, IECEx, FM, and CSA standards, ensuring compliance with global safety regulations. The device features robust signal isolation, capable of handling up to 1000 V AC, making it suitable for industrial applications requiring high levels of safety. It supports input and output ranges of 4-20 mA, powered by a standard 24 V DC supply. The compact design measures 95 mm x 60 mm x 35 mm and weighs only 0.2 kg, making it easy to install in tight spaces. With an environmental rating of IP65, this isolator can withstand harsh conditions, including temperatures ranging from -40°C to +85°C during operation and -55°C to +90°C during storage. The Eaton MTL 8715-CA-BI offers unparalleled reliability and safety, making it an essential component for any process control system in hazardous areas.
