GE 369-HI-0-M-0-0 – 369 Motor Management Relay with Metering Package

Control Power nominal:20 VA; maximum: 65 VA

Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz

Dimensions:approx. 29.6cm H x 10.7cm W x 20.5cm L

Event Record Triggers:power fail, alarms, self test, inhibit, trip, waveform capture

Operating Range:-40°C (-40°F) to +60°C (140°F)

Storage Range:-40°C (-40°F) to +80°C (176°F)

Metering Package:Available

RTD Inputs:Optional

Differential Switch Time Delay:<200 ms

Insulation Class:I

Phase Current Input Conversion:True RMS, 1.04 ms/sample

    The GE 369-HI-0-M-0-0 Motor Management Relay offers unparalleled reliability and efficiency for industrial motor applications.

     With its advanced metering capabilities, users can monitor critical motor parameters in real-time, reducing downtime and maintenance costs.

     This relay is equipped with a non-isolated RS232 port and RS485 port for seamless communication, ensuring that operators have access to accurate data for decision-making.

     Its compact design allows for easy installation in tight spaces, making it suitable for a variety of industrial settings.

     The robust construction and wide operating temperature range make it ideal for harsh environments.

     Additionally, the optional metering package and RTD inputs provide flexibility and precision in motor management.
