Manufacturer:GE Industrial Systems
Series:Ex2100 Excitation Control
Part Number:IS200DSPXH1DBC
Functional Description:Digital Signal Processor Control Board
Functional Acronym:DSPX
PCB Coating:Conformal Coating
Functional Revision:1D
Artwork Revision:C
Instruction Manual:GEI-100488
Clock Speed:60 MHz
I/O Connectors:P1 backplane, P5 DSP emulator, P6 engineering monitor
Onboard Memory:FLASH, RAM, NVRAM
Interfaces:Two (Master or Slave) 5 Mb/s ISBus interfaces
The IS200DSPXH1DBC is part of the GE Industrial Systems EX2100 series, specifically designed for excitation control applications. It boasts a robust digital signal processor running at 60 MHz, providing reliable and efficient performance.
This control board features conformal coating to protect against harsh environmental conditions, ensuring longevity and durability. It includes a boot loader, application code, and configuration parameters onboard for easy integration and customization.
The IS200DSPXH1DBC supports two ISBus interfaces, allowing it to function as either a master or slave device. This versatility makes it suitable for a wide range of industrial automation projects.
With its advanced firmware and memory configurations including FLASH, RAM, and NVRAM, the IS200DSPXH1DBC offers enhanced data processing capabilities and secure storage options. Its design facilitates seamless integration with existing systems and enhances overall system performance.
Whether you’re upgrading an existing setup or building a new control system, the IS200DSPXH1DBC is a reliable choice for your industrial automation needs.
