GE SR750-P5-G1-S1-HI-A20-R – High Performance Feeder Management Relay

Brand:GE

Model:SR750-P5-G1-S1-HI-A20-R

Baud Rate:300 to 19200 baud

Frequency Range:25 to 60 Hz nominal

Operating Environment Humidity:Up to 90% non-condensing

Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01

Relay Dimensions:Approx. 18cm W, 16.5cm L, 21.5cm H

Current Inputs:5 A phase current inputs, 1 A zero sequence current inputs

Voltage Inputs:Sensitive ground current inputs

Communication Protocol:Modbus RTU or DNP 3.0

Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states, and 8 output relays

    The GE SR750-P5-G1-S1-HI-A20-R is meticulously engineered to provide robust protection and control capabilities for industrial distribution systems.

     Its advanced features include precise measurement of phase currents and voltages, essential for reliable system operation.

     With a wide range of communication protocols like Modbus RTU and DNP 3.

    0, it integrates seamlessly with various industrial control systems.

     The relay supports a variety of protective functions including overcurrent protection, under/overfrequency protection, and ground fault protection, ensuring comprehensive safety and efficiency.

     Its compact design allows easy installation in standard 19-inch panels, making it a versatile choice for modern industrial applications.
