Manufacturer:Siemens
Model Number:6ES5470-7LA12
Type:Digital Output Module
Voltage Rating:24 V DC
Current Rating:0.5 A per channel
Channels:8 channels
Protection:Short circuit protection
Operating Temperature Range:-25°C to +60°C
Storage Temperature Range:-40°C to +85°C
Humidity Range:5% to 95% non-condensing
Dimensions:Width: 28 mm, Depth: 114 mm, Height: 100 mm
Weight:0.2 kg
Certifications:CE, UL, CSA
The Siemens 6ES5470-7LA12 is a robust and versatile digital output module designed for industrial control systems. It provides reliable and accurate control over a wide range of digital devices, making it ideal for use in complex manufacturing processes. With 16 channels, each capable of handling up to 0.5 A, this module ensures efficient and stable performance. The voltage rating of 24 V DC makes it compatible with a variety of industrial devices, and its operating temperature range from -25°C to +60°C allows for use in harsh environments. The protection rating of IP20 ensures that the module is safe from dust and small objects, providing long-lasting reliability. The compact design and lightweight construction make installation and maintenance easy and efficient. Whether you’re upgrading an existing system or building a new one, the Siemens 6ES5470-7LA12 is a reliable choice for your digital output needs.
