Startup Time:6 ms max.
Control Velocity Output:-10 to 10 V
Data Backup:Backup using the CPU module
External Contact Output:Servo on, driver reset and brake off
Encoder Type:Incremental encoder (phaseA/B)
Max. Line Driver Speed:2M pps max.
Multiplication Mode:4-time multiplication mode
Control System:Semi-closed loop control (with voltage output for velocity control) based on encoder feedback
External Contact Input:Limit switch, driver alarm, home
The YOKOGAWA F3NC01-0N industrial positioning module offers unparalleled precision and reliability for control applications. With a maximum startup time of just 6 ms, this module ensures swift response times, making it perfect for real-time control scenarios. Its velocity control output ranges from -10 to 10 V, providing a wide range of control options. Data backup is seamlessly managed through the CPU module, ensuring continuous operation without data loss. The external contact output capabilities allow for servo activation, driver reset, and brake deactivation, enhancing operational efficiency. The incremental encoder supports phase A/B signals at a maximum pulse rate of 2 Mpps, further improving accuracy. In 4-time multiplication mode, the encoder delivers exceptional resolution. The semi-closed loop control system, based on encoder feedback, guarantees stable and precise positioning. Additionally, the external contact input allows for integration with limit switches, driver alarms, and home signals, providing robust monitoring and control functions.
